Rotameters

This Acrylic Flowmeter has a Dual Direct Reading Scale with yellow backing for easy viewing of Argon flow values. Viton^® Seals, 3/4" FNPT and Polypropylene End fittings are standard. The float/guide material is 316 Stainless Steel. This Flowmeter is designed for inline mounting and can handle a Maximum Flow Rate of 2500 LPM (90 SCFM). Valve Included.

Acrylic In-Line Flow Meter with 316 Stainless Steel Guide Rods, Polypropylene Connector, No Valve - Water

Acrylic In-Line Flow Meter, Polypropylene Connector, No Valve - Water

These compact, durable flow meter units are injection molded of heat and chemical resistant Polysulfone. To facilitate inline mounting, these meters feature Quik Loc (half union) connectors that couple the meter body to the pipe connectors at each end of the flow meter. The 6B0100 line has a fluid flow range of 0.025 GPM to 10 GPM.

These compact, durable flow meter units are injection molded of heat and chemical resistant Polysulfone. They feature Quik Loc (half union) connectors that couple the meter body to the pipe connectors at each end of the flow meter. These meters are designed with curved connections for easy panel mounting.

With connections of 3/8" MNPT or 1/2" MNPT, the 6B0101 has a fluid flow range of 0.025 GPM to 10 GPM.

The 6B0300-H2O is a high volume flow meter offering excellent accuracy and repeatability. Combined with a durable injection molded Polysulfone meter body and connections, this flow meter offers cost effective 316 SS internal parts. This flow meter is designed for inline mounting. With a 1" FNPT connection, this line has a liquid flow range of 0.5 to 40 GPM (2 - 155 LPM). Half unions couple the meter body to the connectors at each end of the flow meter, facilitating both installation and maintenance.

The 6B0301-H2O is a high volume series of flow meters offering excellent accuracy and repeatability. Combined with a durable injection molded Polysulfone meter body and connections, this flow meter offers cost effective 316 SS internal parts. This flow meter is designed to be panel mounted. With a 1" FNPT connection, this line has a liquid flow range of 0.5 to 40 GPM (2 - 155 LPM). Half unions couple the meter body to the connectors at each end of the flow meter, facilitating both installation and maintenance.

The 6B05 series flow meter's rib guided polysulfone contains no metal in the fluid path. This makes the flow meter desirable in highly corrosive environments or deionized water applications. The 6B0500-PVC is equipped with 1/2" or 3/4" FNPT Adapters.

The 6B05 series flow meter's rib guided polysulfone contains no metal in the fluid path. This makes the flow meter desirable in highly corrosive environments or deionized water applications. The 6B0501-PVDF is equipped with 1/2" or 3/4" PVDF FNPT Adapters.

The 6B06 series flow meter's rib guided polysulfone contains no metal in the fluid path. This makes the flow meter desirable in highly corrosive environments or deionized water applications. The 6B0601-PVDF is equipped with 1" FNPT Adapters.

Incorporating traditional variable area precision glass technology, these rugged PTFE in-line flow meters offer accurate and economical solutions to medium flow range measurements. These meters are designed with unique rotatable scales of dual air-water direct reading graduations showing SCFM and SLPM (air), as well as GPM and LPM (water) markings. No Valve.

Incorporating traditional variable area precision glass technology, these rugged brass in-line flow meters offer accurate and economical solutions to medium flow range measurements. These meters are designed with unique rotatable scales of dual air-water direct reading graduations showing SCFM and SLPM (air), as well as GPM and LPM (water) markings. No Valve.

Designed for low flow rates, these 65mm Single Tube Brass Flow Meters are precision instruments embodying the inherent simplicity, versatility and economy of the classical variable area meter. They are particularly suitable for metering carrier gases in chromatography, in manufacturing processes, liquid and gas measurements in laboratories, pilot plants, flow and level indicating and controlling gases. No Valve.

The 6B0305-H2O is a high volume series of flow meters offering excellent accuracy and repeatability. Combined with a durable injection molded Polysulfone meter body and connections, this flow meter offers cost effective 316 SS internal parts. This flow meter is designed for inline mounting. With connections of 1.5" FNPT, this line has a liquid flow range of 0.5 to 40 GPM (2 - 155 LPM). Half unions couple the meter body to the connectors at each end of the flow meter, facilitating both installation and maintenance.

Incorporating traditional variable area precision glass technology, these rugged stainless steel in-line flow meters offer accurate and economical solutions to medium flow range measurements. These meters are designed with unique rotatable scales of dual air-water direct reading graduations showing SCFM and SLPM (air), as well as GPM and LPM (water) markings. No Valve.

Designed for low flow rates, these 65mm Single Tube Brass Flow Meters are precision instruments embodying the inherent simplicity, versatility and economy of the classical variable area meter. They are particularly suitable for metering carrier gases in chromatography, in manufacturing processes, liquid and gas measurements in laboratories, pilot plants, flow and level indicating and controlling gases. No Valve.

Made entirely of PTFE, PFA and PCTFE, the In-Line PTFE Flow Meter is excellent for high-purity applications or use with corrosive liquids. These meters feature chemically inert wetted components and a removable protective shield. Each meter is individually leak tested.
